| Connection Diameter Machine Side (DCONMS) | 1/2″ | Measurement Type | Inch |
| Shank Type | Round | Body Material | Carbide |
| Body Diameter (BD) | 0.299″ | Overall Length (OAL) | 4-1/2″ |
| Coolant Supply Property (CSP) | External | Unit | I |
| Tool Type | Cylindrical Shanks |
Product Features
| Family Description | MULTI-MASTER, 89° conical shanks for solid carbide interchangeable milling heads. Available are steel, solid carbide and tungsten shank materials. Tungsten shanks have coolant holes | FamilyName | MM S-D (89° conical shanks) |
| Remarks | For adaptation click on More Info Do not apply lubricant to the threaded connection. Shank Material (Shank m.): S-steel,C-carbide,W-tungsten | BrandName | Iscar |
| COO | Israel |
Shipping Info
Weight per item
0.3417
Name
Extensions
FamilyName
MM S-D (89° conical shanks)
BrandName
Iscar
Related Documentation
